Maxmotion Electric Fan Motors Silver

A durable and versatile motor design that can be base or flange mounted to equipment operating in wet and severe conditions, and where wash down duty and corrosive elements are found such as in the food processing, bottling and conveyor industries. NEMA Design B meets MG-1 Part 31. Meets or exceeds MEPS as described by US Department of Energy in docket 10CFR431 and Natural Resources Canada’s Amendment 14. Also CSAus and CE Certified. Service Factor of 1.15. Highest quality Enamel coated Corona resistant inverter duty magnet wire. VPI with additional drip and bake. Insulation non hygroscopic class F with class B temperature rise. Bearing double sealed with Lithium grease -30 Deg to 180 Deg C. Enclosure protection meets ingress protection standard IP66. Paint free with all 304 Stainless Steel housing and shaft. Moisture proof sealant on all machined fits and shielded Viton type double lip seal. Four condensation plugs on each end shield for mounting flexibility. The round welded terminal box design comes completely encapsulated and offers two points of entry for easy access to the terminals. All while eliminating points where contaminants can build up, and maintaining the motors IP66 rating. Inverter duty 10:1 Constant Torque, 20:1 Variable Torque. Nameplate permanently etched to stainless steel housing. Warranty 18 months from date of fabrication.
